Solidstate Amplifier

Product Overview

Our high-power amplifiers are engineered to deliver clean, controllable RF output from modest input levels, emphasizing efficiency, linearity, and long-term stability.

ALC and gain control help you hold target levels under varying conditions, while built-in protection safeguards both the amplifier and connected equipment.

With serial control, rugged construction, and flexible configuration, these units integrate smoothly into new or existing platforms. Choose from proven standard options or collaborate with our engineers on a custom design matched to your band, output goals, and environmental requirements.

Key Features

  • Extremely cost competitive purchase price
  • Various range frequency covering
  • Wide range power output from low to high
  • Isolator protected output
  • Wide Temperature range
  • Field Proven reliability
  • Smaller size Rugged design
  • Several Standard Options available as well as Custom Design

Applications

  • TERA/GSM/DCS/UMTS/WCDMA/LTE/5G System
  • RF Repeater
  • DAS (Distributed Antenna System)
  • RRH (Remote Radio Head)
  • Amplifier for Digital Television
Part Number Freq Start (MHz) Freq Stop (MHz) Output Power (dBm) Gain (dB) Size (mm) Datasheet
EBS-6000M10000-47-40 6000 10000 47 50 482.6*132*588
EBS-6000M18000-40-40 6000 18000 40 40 240*92*330
ESM-0087-43-50 87 250 43 49 160*90*25
ESM-0453-46-45 453 488 46 25 127*95*25
ESM-0700-45-47 700 800 45 47 150*120*28
ESM-0758-40-45 758 805 40 3 127*95*25
ESM-0760-30-45 760 790 30 1 127*95*25
ESM-0769-46-45 769 775 46 25 127*95.25*25.4
ESM-0806-40-45 806 860 40 3 127*95*25
ESM-0816-45-45 816 824 45 30 100*80*25
ESM-0840-30-45 840 870 30 1 127*95*25
ESM-0850-46-45-B 850 860 46 25 127*95.25*25.4
ESM-0850-46-45 850 870 46 25 127*95.25*25.4
ESM-0851-46-45 851 854 46 25 127*95.25*25.4
ESM-0935-46-46 935 960 46 25 127*95.25*25.4
ESM-2700-56-32 2700 3100 56 32 300*200*32
ESM-2700-59-35 2700 3100 59 33 300*200*32
ESM-2800-55-30 2800 3500 55 30 240*150*32
